1 Ø digital Control Panel

Overview

  • Overload & dry running protection
  • Over voltage protection
  • Under voltage protection
  • Provide Auto / Manual System
  • Variable current amp setting
  • Led indications for water level in tank
  • Two tank controller
  • Available with S.S Sensors / magnetic sensors and float switch
  • In built volt and amp meter(digital)
  • Facility to connect ellico water level controller adeptor(LLC-001)

Technical Specification

Supply voltage 230 VAC, 50Hz ± 20%
Current range 2-20 Amp
Switching device Power relay
Sencing element S.S prod
Indication Dryrun, O/L, OH, OL, UH, UL,
High Volt, Low Volt
Auto / manual facilities yes
Under voltage (low voltage) 130V AC, ± 5%
Over voltage (high voltage) 280V AC, ± 5%
Start capacitor As Per Motor range in HP
Run capacitor As Per Motor range in HP
Enclosure Metal box
Weight 3.500 kg
Dimension (mm)
Dimension (HXWXD) (203 X 318 X 90) mm
Base mounting Yes
