- Easy to operate
- Surface mountable
- Two tank controller
- LED indications for water level in tank
- Available with S.S Sensors / magnetic Sensors / float switch
- Automatic Control of starter according to set water level in tanks
- Din Rail mounting facilities
| Supply voltage | 230/415 VAC , 50 Hz ± 10% |
| Switch device | Relay |
| Output contact Rating | 6 Amp |
| Sencing element | S.S Prod |
| Indication | motor on Over head high Over head low Under ground high Under ground low |
| Auto/ manual facilities | Yes |
| Enclosure | PVC box |
| Weight | 0.582 gms |
| Dimension (mm) | |
| -Dimension (HXWXD) | (119 X 56 X 95) mm |
| -Din Rail mounting | Yes |
- Mcc panels of water pump in hotels, house, industries
- High rise towers, housing societies, commercial complexs, municipal water stations, etc
