- Overload dry running protection through prod
- Over voltage protection
- Under voltage protection
- Provided auto / manual system
- Variable current amp setting
- Led indications for water level in tank
- Two tank controller
- Available with S.S Sensors / magnetic sensors and float switch
| Supply voltage | 230 / 415 VAC, 50Hz ± 20% |
| Current range | 4-12 Amp 8-20 Amp |
| Switching device | Power relay |
| Sencing element | S.S prod |
| Indication | Motor ON, O/L, OH,OL, UH, UL High volt, low volt, power ON |
| Auto / manual facilities | yes |
| Under voltage (low voltage) | 130 VAC ± 5% |
| Over voltage (high voltage) | 280 VAC ± 5% |
| Start capacitor | NO |
| Run capacitor | NO |
| Enclosure | PVC box |
| Weight | 0.940 gms |
| Dimension (mm) | |
| -Dimension (HXWXD) | (180X147X80) mm |
| -Base mounting | Yes |
- House, high rise towers, housing societies, industries, commercial complex etc
